Illustrative photo
Some product features, such as color or dimensions, may vary in the photo. For more technical information, please refer to the "See product in catalog" section.
Ref. 51250304 OEM (43515D)
HYDRAULIC STEERING CYLINDER UC95-OBF/1 ULTRAFLEX
€664.57
VAT included
Available
Choose another model
Product details
-
Name
Hydraulic steering cylinder
-
Model
UC95-OBF/1
-
Horse power (HP)
175
-
Stroke (mm)
186
-
Volume (cm3)
95
-
Minimum Pipeline
10m
Related products
-
Ref. 52203334
CYLINDER VHM EX175HP + CONNECTIONS LECOMBLE SCHMITT
/ LECOMBLE SCHMITT
€448.37 -
Ref. 52203333
CYLINDER VHM EX125HP + CONNECTIONS LECOMBLE SCHMITT
/ LECOMBLE SCHMITT
€402.33 -
Ref. 52203315
CYLINDER FOR FB80HP 557mm 70cc LECOMBLE SCHMITT
/ LECOMBLE SCHMITT
€383.40 -
Ref. 52203335
CYLINDER VHM EX225HP + CONNECTIONS LECOMBLE SCHMITT
/ LECOMBLE SCHMITT
€509.79 -
Ref. 52203572
STEERING CYLINDER EX3500HP + S.S. CONNEC LECOMBLE SCHMITT
/ LECOMBLE SCHMITT
€913.05 -
Ref. 51250305
HYDRAULIC STEERING CYLINDER UC128-OBF/1 ULTRAFLEX
/ ULTRAFLEX
€852.19 -
Ref. 51250303
HIDRAULIC STEERING CYLINDER UC81-OBF ULTRAFLEX
/ ULTRAFLEX
€515.53 -
Ref. 51250306
HYDRAULIC STEERING CYLINDER UC128-OBF/2 ULTRAFLEX
/ ULTRAFLEX
€852.19 -
Ref. 13000021
GAS SPRING 510mm 27.2kg S.S. IMNASA
/ IMNASA
€40.11 -
Ref. 13000014
GAS SPRING 381mm 13.5kg S.S. IMNASA
/ IMNASA
€35.11 -
Ref. 13000211
RAISER, GAS LIFT 330+270mm IMNASA
/ IMNASA
€15.79 -
Ref. 13000020
GAS SPRING 510mm 13.5kg S.S. IMNASA
/ IMNASA
€40.11 -
Ref. 13000084
GAS SPRING 480 18/8 27k STAINLESS STEEL IMNASA
/ IMNASA
€43.04 -
Ref. 13000017
GAS SPRING 437mm 13.5kg S.S. IMNASA
/ IMNASA
€40.84 -
Ref. 13000022
GAS SPRING 510mm 68kg S.S. IMNASA
/ IMNASA
€44.52 -
Ref. 13000018
GAS SPRING 437mm 27.2kg S.S. IMNASA
/ IMNASA
€40.86 -
Ref. 13000209
RAISER, GAS LIFT 220+135mm IMNASA
/ IMNASA
€13.96 -
Ref. 13000015
GAS SPRING 381mm 27.2kg S.S. IMNASA
/ IMNASA
€35.11 -
Ref. 13000208
RAISER, GAS LIFT 320+230mm IMNASA
/ IMNASA
€15.48 -
Ref. 13000056
GAS SPRING 305-509mm 27.2kg NITRIDE IMNASA
/ IMNASA
€13.94 -
Ref. 25400003
PISTON LARGO 220 MM
€151.94 -
Ref. 13000212
RAISER, GAS LIFT 320+230mm IMNASA
/ IMNASA
€15.48 -
Ref. 13000210
RAISER, GAS LIFT 400+300mm IMNASA
/ IMNASA
€20.41 -
Ref. 13000123
GAS SPRING 549 18/8 200N INOX IMNASA
/ IMNASA
€39.58 -
Ref. 13000008
GAS SPRING 254mm 13.5kg S.S IMNASA
/ IMNASA
€32.09
Product description
The UC95-OBF/1 hydraulic steering piston is recommended for use with outboard motors of 175 Hp and when the vessel's speed does not exceed 55 mph (48 knots), so it is not intended for use in competition applications.
Data of interest
TECHNICAL DESCRIPTION
- The piston volume is 95 CC - 5.8 CU.IN.
- Its stroke is 186 mm (7.3"), with an output force of 278 kg (613 IBS).
- The internal diameter of the cylinder is 30 mm (1.18").
- Balanced: the number of turns from stop to stop is equal on port and starboard or vice versa.
- Innovative design, with a split cylinder mounting rod, with pins for easy installation and with bushings to prevent friction with the motor tilt tube.
- Contains adjustable pins for easy installation.
- Stainless steel connecting bolt with high strength (ULTRABOLT).
- Replaceable cylinder end caps.
